Compatible Receiver To Suit BFT

BFT Compatible Garage/Gate Receiver

Frequency: 433.92 MHz

Capacity: 500 remotes

Channels: 2

Dimensions: 60W x 95H x 30D mm

Voltage: 12-24V

For compatible remotes for this receiver please Click Here

Terminal/Wiring Guide:

V+ (receiver) > usually called 12V, 24V V+ (motor)
GND (receiver) > usually called COM, Common, GND, 0V (motor)
CH1 - Left (receiver) > usually called PB, WB, OSC (motor)
CH1 - Right (receiver) > usually called COM, Common, GND, 0V (motor)

Please Note: Receivers are not included with instructions or wires and there will be no specific instructions on how to wire/connect this to your motor. You must cross reference the guide above with your motor manual. For easy DIY receiver upgrade, please refer to our receiver upgrade kits.

Please Note: All receiver are recommended to be installed by a professional

Disclaimer:

Remote Pro distributes remote controls which are compatible with the door or garage motors and receivers produced by other manufacturers, and which are substitutes for remote controls produced by those manufacturers. Except where a product is expressly stated to be a "genuine" remote, our remote controls are not produced by, and are not authorised, endorsed or approved by these other manufacturers.
